Product Details:
|
| Features: | High Transparent Quartz Window, High Sensitivity, Low Dark Current | Chip Size: | 1 Mm2 |
|---|---|---|---|
| Package: | SMD 3535 | Response Wavelength: | 210-370 Nm |
| Typical Application: | Ultraviolet Disinfection Lamp Monitoring | ||
| Highlight: | GS-UVC-3535LQC UV Photodiode Sensor,UV Photodiode Sensor Air Purification,UVC Photodiode Sensor |
||
Product Description:
GS-UVC-3535LQC UVC Photodiode For Air Purification Water Quality Measurement
Features:
General Features:
l Selective response to UVC band
l Photovoltaic mode operation
l SMD 3535 ceramic package with quartz window
l Good solar blindness
l High responsivity and low dark current
Applications:
air purification, water quality measurement
Specifications: Parameters Symbol Value Unit Maximum ratings
Operation temperature range Topt -25-85 oC
Storage temperature range Tsto -40-85 oC
Soldering temperature (3 s) Tsol 260 oC
Reverse voltage Vr-max -10 V
General characteristics (25 oC) Chip size A 1 mm2 Dark current (Vr = -1 V) Id <1 nA Temperature coefficient (@265 nm) Tc 0.05 %/ oC Capacitance (at 0 V and 1 MHz) Cp 18 pF> <1 nA Temperature coefficient Tc 0.065 %/ oC Capacitance (at 0 V and 1 MHz) Cp 1.7 pF>
<1 nA Temperature coefficient (@265 nm) Tc 0.05 %/ oC Capacitance (at 0 V and 1 MHz) Cp 18 p>
Specifications:
| Wavelength of peak responsivisity | λ p 285 nm |
| Peak responsivisity (at 385 nm) | Rmax 0.178 A/W |
| Spectral response range (R=0.1×Rmax) | 225-290 nm |
| UV-visible rejection ratio (Rmax/R450 nm) | - >10 - |
